BlackVue CM100G LTE Module (NA Version) | BlackVue | Dash Cam Accessories | BlackboxMyCar
SKU BV-CM100LTE

BlackVue CM100G LTE Module (NA Version)

Availability:
in stock, ready to be shipped
Save 15% Save 15%
$159.99
$159.99 - $159.99
$159.99
$135.99
$135.99 - $135.99
$135.99
Best Price Guaranteed
Every order includes:

Chat with an expert

Talk to a dash cam expert before you order.

Contact an expert

BlackVue CM100G LTE Module: North America

Give a supported BlackVue dash cam its own 4G data connection for remote viewing, notifications and other available Cloud features. The CM100G LTE connects to the camera’s dedicated USB port and draws power from the camera.

The included 3m cable, approximately 10ft, gives you room to position the module near a top corner of the windshield. This is the North American version. The FAQs explain camera compatibility and mobile-network requirements.

4G LTE

Cloud Connection

3m Cable

Camera Powered

Choose the exact camera connection

BlackVue lists the ELITE family, DR970X and DR970X Plus, DR970X Box Plus, DR770X and DR770X Box/Box Pro, DR900X/Plus and DR750X/Plus families for this module. Check the exact camera generation, available USB connection and current firmware before installation.

Current options include the DR770X-2CH Series II and ELITE 8 2-channel. Cameras with built-in LTE already have their own cellular connection; this is not a general-purpose USB modem for any dash cam.

CM100G LTE also contains a GNSS receiver. How the camera uses external location data depends on its exact model and firmware. Do not buy the module solely as a GPS upgrade without checking that pairing.

BlackVue connectivity module with attached camera cable and right-angle micro USB plug

Install the SIM and route the included 3m cable

With the camera powered off, remove the screw securing the SIM cover and use the eject tool to open the tray. Fit an activated nano-SIM in the correct orientation, return the tray and secure the cover. The module needs a plan that supports 4G LTE data.

Clean and dry the mounting area, then attach the module near a top corner of the windshield without blocking the driver’s view. Connect the supplied lead to the supported camera USB port and secure the route with the cable clips. Leave space around airbag paths and moving trim.

Open the BlackVue app and complete the camera’s Cloud connection settings. Enter the carrier’s APN if automatic setup does not work, then confirm a remote connection before finishing the installation.

BlackVue module with SIM tray, cover and retaining screw removed

Cloud access depends on coverage and power

The module supplies a cellular connection; the camera and its service plan determine which remote features are available. Remote Live View, event notifications and uploads need network coverage, remaining data and a powered camera. Cellular service and Cloud subscription allowances are separate.

For parked use, the camera needs an appropriate hardwire installation or a compatible battery such as the BlackVue B-130A. When the camera shuts down, the module also loses power. LTE use adds to the system’s energy demand.

On cameras that support Mobile Hotspot, the camera can share the connection with up to five Wi-Fi devices. Those devices use the same mobile data allowance. One module connects by cable to one camera; it is not a multi-camera USB hub.

Diagram of a BlackVue dash cam connecting to its phone app through the Cloud
What's Included
  • One North American CM100G LTE connectivity module with 3m USB harness cable
  • SIM eject tool
  • Four cable clips
  • Four pieces of double-sided mounting tape
  • Screwdriver
  • User guide
Specifications
Operating Temperature −35°C to 75°C (−31°F to 167°F)
Dimensions 90 × 60 × 10mm
Warranty 2-year manufacturer warranty
Model / version CM100GLTE; North America
Cellular technology 4G LTE Category 4; Quectel EC25-A
North American LTE bands B2 / B4 / B12
Theoretical LTE rate Up to 150Mbps download / 50Mbps upload; actual rates vary
SIM type Activated nano-SIM with compatible 4G data service; sold separately
Camera connector Micro USB Type-B harness for supported BlackVue cameras
Included cable 3m, approximately 10ft
Power source Supported dash cam USB port; no independent battery
Typical supply 5V / 1A from the supported camera connection
GNSS receiver GPS L1, GLONASS G1, Galileo E1 and BeiDou B1; camera support required
Weight 110g
Storage temperature −40°C to 85°C (−40°F to 185°F)
Frequently Asked Questions

Is the 3m cable included?

Yes. Current stock includes the 3m cable, approximately 10ft. You do not need to buy that lead separately.

Which BlackVue cameras work with it?

Supported families include ELITE, DR970X/Plus and DR970X Box Plus, DR770X and its Box/Box Pro models, DR900X/Plus and DR750X/Plus. Check the exact generation, USB port and firmware. A USB port on another camera does not establish compatibility.

Do I need it if my camera has built-in LTE?

Normally no. A built-in LTE camera has its own SIM connection. Check your complete model name so you do not buy a second cellular module unnecessarily.

Which carrier should I use?

For the US, BlackVue recommends a direct T-Mobile data plan. Confirm the module IMEI, plan and APN with the carrier before buying service. Do not assume an MVNO works because it shares a larger carrier’s network.

Can I use a SIM advertised for 5G?

The module itself uses 4G LTE. BlackVue says a hybrid 4G/5G SIM may work if its service supports fallback to 4G; a 5G-only SIM is unsupported. Confirm the exact data plan and module compatibility with the carrier.

Does the package include internet or a SIM?

No. Buy and activate a compatible nano-SIM data plan separately. A BlackVue account and any required Cloud service plan are also separate from cellular service.

Why does the app ask for an APN?

An APN identifies the carrier’s mobile data connection. Use the settings supplied for your exact SIM and plan, then confirm the camera shows a Cloud connection. If connection fails, check activation, SIM seating, coverage and the APN.

Will it stay online with the ignition off?

Only while the compatible camera remains powered and has cellular coverage and data. Use a suitable parking-power setup. When a voltage cutoff, battery depletion or camera setting shuts the camera down, the module also stops.

Can it provide Wi-Fi for passengers?

Yes, through a BlackVue camera that supports Mobile Hotspot, with an active data connection. Up to five Wi-Fi devices can share the camera’s network. Their traffic uses the SIM plan’s data and can compete with camera uploads.

Is 480Mbps the mobile internet speed?

No. The 480Mbps figure refers to the USB 2.0 interface. The module’s LTE Category 4 specification is up to 150Mbps down and 50Mbps up under theoretical conditions; coverage, network load and the plan determine actual speeds.

Does CM100G LTE add GPS to every compatible camera?

The G model includes a GNSS receiver, but external GPS use is camera- and firmware-dependent. Confirm the exact camera if external GPS is your reason for buying it.

Does it work worldwide?

This is the North American B2/B4/B12 version. Other regions use different module versions and bands. Roaming permission alone does not make this module compatible with every foreign network.

What warranty coverage applies?

This accessory has a two-year BlackVue manufacturer warranty, which BlackboxMyCar honors. Our default retailer coverage is six months unless otherwise stated; it does not shorten this product’s two-year manufacturer coverage.
